| Rated Voltage | 12V |
| Nominal Capacity | Nominal Capacity (25℃):
C20,1.75V/cell: 12Ah |
| Dimension | Length: 151mm (5.94inches)
Width: 98mm (3.86inches)
Container Height: 95mm (3.74inches)
Total Height: 101mm (3.98inches)
|
| Approx Weight | 3.24kg (7.14lbs) |
| Terminal | T1/T2 |
| Container Material | ABS (UL94 HB or V-0 optional) |
| Short-circuit current | 336A |
| Internal Resistance | Internal Resistance (25℃):
Approx 19 mΩ (Fully charged) |
| Operating Temp. Range | Discharge: -15~50℃ (5~122°F)
Charge: -20~40℃ (-4~104°F)
Storage: -15~40℃ (5~104°F)
|
| Nominal Operating Temp. Range | 25±3℃ (77±5°F) |
| Max.Charging Current | 0.3C |
| Charge voltage | Standby Us: 2.25-2.30V/cell
Cycle Use: 2.35-2.45V/cell
|
| Temp. Coeffcient | -3mV/cell/℃
-5mV/cell/℃
|
| Effect of temp. to Capacity | 40℃ (104°F): 103%
25℃ (77°F): 100%
0℃ (32°F): 86%
|
| Self Discharge | ≤3% per month at 25°C (77°F).
LP series batteries may be stored up to 6 months at 25°C (77°F) and then a freshening charge is required.
For higher temperatures, the time interval will be shorter. |
