| Case Size | Mid Tower |
| Motherboard Support | EATX (12"x10.9")
ATX
Micro-ATX
Mini-ITX
DTX
Mini-DTX
|
| Drive Bays | 4 x 2.5" Bay
4 x 2.5"/3.5" Combo Bay
|
| Expansion Slots | 8
2 (additional vertical)
|
| Front I/O Port | 2 x USB 3.2 Gen1
1 x USB 3.2 Gen 2x2 Type C
2 x USB 2.0
Fan Control Button
Reset Button
|
| Tempered Glass | Left Side |
| Radiator Support (Top) | 120 mm
140 mm
240 mm
280 mm
360 mm
420 mm
|
| Cooling Support (Front) | 2 x 200 mm |
| Cooling Support (Top) | 3 x 120 mm
3 x 140 mm
|
| Cooling Support (Rear) | 1 x 120 mm
1 x 140 mm |
| Dust Filter | Front
Top
Bottom
|
| Pre-installed Fans (Front) | 2 x 200 mm |
| Pre-installed Fans (Rear) | 1 x 140 mm
PWM
|
| Maximum CPU Cooler Height | 190 mm |
| Maximum GPU Length | 450 mm |
| Maximum PSU Length | 190 mm |
| Removable Dust Filters | Front
Top
Bottom
|
| Maximum Cable Management Space | 30 mm |
| Dimensions | 593 x 560 x 245 mm |
| Weight | 15.8 kg |
