| CPU Support | Support Intel Socket 1155, supports INTEL 2nd and 3rd generation CPU |
| Chipset | Intel H61 Chipset |
| On-Board Graphics | Integrated Graphics Processor-Intel HD Graphics support |
| Memory | DDR3 1066/1333/1600 memory |
| DIMM | 2 x Memory Slots |
| LAN | On board Realtek 100Mbit, 10/100 Mbit adaptive |
| Audio | Realtek 6 Channel Audio Codec |
| SATA | 3 x SATA 3.0 port, 1 x M.2 |
| Rear I/O | 1 x VGA port, 1 x HDMI port, 6x USB 2.0 port, 1 x LAN jack, 3 x Audio jack |
| Internal I/O | 2 x USB 2.0 pin header supports additional 4 USB 2.0 ports 1 x Front Panel Audio pin header |
| Expansion Slots | 1 x PCI Express x16 slot
1 x PCI E x1 slot |
| Form Factor | Micro-ATX (17 x 21.5 cm) |
| OS Support | Support Windows 7 / 8 / 8.1 / 10(x64) |
| Mounting | 4 mounting holes |
| Accessories | 1 x SATA cable, 1 x I/O Backboard, 1 x User Manual, 1 x Driver CD |
| Remark | All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets. PCB color and bundled software versions are subject to change without notice. The brand and product names mentioned are trademarks of their respective companies |
| Warranty | 3-Year Brand Warranty |
